Ford F-250 Towing Capacity Chart: All Years & Engines (2011–2026)
Ford F-250 Super Duty towing capacity ranges from 15,000 lbs to 22,800 lbs depending on model year, engine, cab configuration, and hitch type. The maximum F-250 tow rating is 22,800 lbs for fifth-wheel and gooseneck towing on 2023–2026 models equipped with the 6.7L Power Stroke diesel and the Gooseneck/Fifth Wheel Towing Package. Conventional trailer towing peaks at 20,000 lbs on the same configuration. Last updated: April 2026.
This complete Ford F-250 towing capacity chart covers every model year from 2011 to 2026 with engine-by-engine ratings for the 6.2L gas, 7.3L Godzilla gas, and 6.7L Power Stroke diesel. Use it to verify your truck's exact rating before buying a trailer or comparing configurations.
Ford F-250 Towing Capacity Chart (2017–2026)
| Model Year | Engine | Hitch Type | Max Tow (lbs) | Notes |
|---|---|---|---|---|
| 2023–2026 | 6.7L Power Stroke Diesel | Gooseneck / 5th Wheel | 22,800 | GN/5W Towing Pkg req'd |
| 2023–2026 | 6.7L Power Stroke Diesel | Conventional | 20,000 | Max Tow Pkg req'd |
| 2023–2026 | 7.3L Godzilla V8 Gas | Conventional | 18,000 | Max Tow Pkg req'd |
| 2023–2026 | 6.2L V8 Gas | Conventional | 15,000 | — |
| 2020–2022 | 6.7L Power Stroke Diesel | Gooseneck / 5th Wheel | 22,800 | GN/5W Pkg req'd |
| 2020–2022 | 6.7L Power Stroke Diesel | Conventional | 20,000 | Max Tow Pkg req'd |
| 2020–2022 | 7.3L Godzilla V8 Gas | Conventional | 18,000 | Max Tow Pkg req'd |
| 2020–2022 | 6.2L V8 Gas | Conventional | 15,000 | — |
| 2017–2019 | 6.7L Power Stroke Diesel | Gooseneck / 5th Wheel | 18,000 | GN/5W Pkg req'd |
| 2017–2019 | 6.7L Power Stroke Diesel | Conventional | 16,800 | Max Tow Pkg req'd |
| 2017–2019 | 6.2L V8 Gas | Conventional | 13,000 | — |
Ford F-250 Towing Capacity: 2011–2016
| Model Year | Engine | Max Conventional Tow (lbs) | Max 5th Wheel (lbs) |
|---|---|---|---|
| 2015–2016 | 6.7L Power Stroke | 17,900 | 21,000 |
| 2015–2016 | 6.2L V8 Gas | 12,100 | 16,800 |
| 2011–2014 | 6.7L Power Stroke | 16,800 | 20,000 |
| 2011–2014 | 6.2L V8 Gas | 12,500 | 16,000 |
F-250 Towing Capacity by Engine
6.7L Power Stroke Diesel (Best for Heavy Towing)
The third-generation 6.7L Power Stroke (2020–present) produces 475 hp and 1,050 lb-ft of torque — the highest torque output of any factory pickup truck diesel. Paired with the Gooseneck/Fifth Wheel Towing Package, it achieves 22,800 lbs — the benchmark for Super Duty capability. For high-frequency heavy towing (horse trailers, large RVs, heavy equipment), this is the only engine to consider in the F-250. The diesel also offers the best fuel economy while towing, typically 14–17 mpg with a mid-size trailer.
7.3L Godzilla V8 Gas (2020–Present)
Introduced in 2020, the 7.3L Godzilla V8 produces 430 hp and 485 lb-ft of torque. It achieves up to 18,000 lbs of conventional towing with the Max Tow Package — 2,000 lbs less than the diesel on conventional towing and significantly less on fifth-wheel applications. The Godzilla's advantages are lower purchase cost, lower maintenance cost, and simpler emissions system (no DPF, no DEF fluid). If you tow under 15,000 lbs regularly, it is a strong value choice.
6.2L V8 Gas (All Years)
The 6.2L Boss V8 has been available across all Super Duty generations since 2011. It produces 385 hp and 430 lb-ft of torque and is rated up to 15,000 lbs conventional on 2020–2026 trucks. It is the base engine choice and is recommended for lighter towing tasks — utility trailers, smaller boats, and loads under 12,000 lbs. For regular heavy towing, the 6.2L requires more frequent downshifts and runs at higher RPM than the diesel or 7.3L.
F-250 vs. F-150 Towing Capacity
The F-250 starts where the F-150 leaves off. The best F-150 (3.5L EcoBoost, 2021–2026) is rated 14,000 lbs. The base F-250 with the 6.2L gas engine already exceeds that at 15,000 lbs, and the diesel goes to 20,000–22,800 lbs. The structural difference is the F-250's heavier frame, upgraded axles, and higher GVWR — it is built for sustained heavy loads, not just occasional towing.
If you regularly tow above 12,000 lbs, the F-250 is the appropriate tool. For towing under 10,000 lbs, the Ford F-150 towing capacity chart shows capable options at a lower price point.
Ford F-250 Towing Capacity FAQ
What is the maximum towing capacity of the Ford F-250?
22,800 lbs — achieved on 2020–2026 models with the 6.7L Power Stroke diesel, Gooseneck/Fifth Wheel Towing Package, and a fifth-wheel or gooseneck hitch. Maximum conventional trailer towing on the same engine is 20,000 lbs.
What engine is best for towing in an F-250?
The 6.7L Power Stroke diesel — it provides the highest tow rating (22,800 lbs), the most torque (1,050 lb-ft on 2020+ trucks), and the best fuel economy under load. For towing under 15,000 lbs, the 7.3L Godzilla V8 is a lower purchase and maintenance cost alternative.
Can a Ford F-250 tow a fifth wheel?
Yes — up to 22,800 lbs with the diesel and Gooseneck/Fifth Wheel Towing Package. This is among the highest fifth-wheel ratings of any pickup truck in the 3/4-ton class.
