Ford F-150 Engine Comparison Chart by Year (2011–2026)
Ford has offered eleven distinct F-150 engines since the 2011 EcoBoost launch redefined what a half-ton truck could do. Choosing the right one, whether you’re buying used or speccing a new build, comes down to matching horsepower, torque,
towing capacity, and real-world reliability to how you actually use the truck. Below is the full lineup broken down by generation, followed by a complete side-by-side spec chart.
Ford F-150 Engine Lineup at a Glance
2011-2026 · Every engine, grouped by era
Ford F-150 Engine Lineup by Generation (2011-2026)
2011-2014: Ford introduced the twin-turbo 3.5L EcoBoost alongside the carryover 3.7L Ti-VCT V6, the 5.0L Ti-VCT V8 (Coyote), and the 6.2L V8 used in heavier-duty and SVT Raptor configurations. This was the model year the EcoBoost badge first appeared on an F-150.
2015-2020: Ford moved the F-150 to a high-strength aluminum-alloy body starting in 2015, adding the 2.7L EcoBoost V6 and replacing the 3.7L with a 3.5L Ti-VCT V6 that same year; the 6.2L V8 was dropped after 2014. The 3.3L V6 replaced the 3.5L V6 for 2018. The 3.5L EcoBoost was significantly reworked for 2017, gaining a new turbocharger design, a 10-speed transmission, and a meaningful jump in output.
2021-2026: The current-generation F-150 kept the 3.3L Ti-VCT V6 as the base engine through 2023 and introduced the 3.5L PowerBoost Full Hybrid. Since 2024, the 2.7L EcoBoost has taken over as the standard engine on most trims, and the 5.2L Supercharged V8 arrived exclusively in the Raptor R.
Want the engine choices for one specific model year? See our Ford F-150 engine options by year chart.
Full Ford F-150 Engine Specs Comparison Chart (All Engines, 2011-2026)
| Engine | Model Years | Horsepower | Torque | Max Towing | Reliability |
|---|---|---|---|---|---|
| 3.7L Ti-VCT V6 | 2011-2014 | 302 hp | 278 lb-ft | 6,100 lbs (2014) | Good |
| 6.2L V8 | 2011-2014 | 411 hp | 434 lb-ft | 11,300 lbs (2014) | Good |
| 5.0L Coyote V8 (Gen 1) | 2011-2014 | 360 hp | 380 lb-ft | 10,000 lbs (2014) | High |
| 3.5L EcoBoost (Gen 1) | 2011-2016 | 365 hp | 420 lb-ft | 11,300 lbs (2014); 12,200 lbs (2015) | Inspect carefully |
| 3.5L Ti-VCT V6 | 2015-2017 | 282 hp | 253 lb-ft | Varies by year | Good |
| 2.7L EcoBoost (original) | 2015-2017 | 325 hp | 375 lb-ft | 8,500 lbs | Good |
| 5.0L Coyote V8 (Gen 2) | 2015-2017 | 385 hp | 387 lb-ft | 11,100 lbs (2015) | High |
| 3.3L Ti-VCT V6 | 2018-2023 | 290 hp | 265 lb-ft | 8,200 lbs (2021-2023) | Good |
| 3.5L EcoBoost (Gen 2) | 2017-2020 | 375 hp | 470 lb-ft | 13,200 lbs | Good |
| 2.7L EcoBoost (updated) | 2018-2023 | 325 hp | 400 lb-ft | Varies by year and cab | Good |
| 5.0L Coyote V8 (Gen 3) | 2018-2020 | 395 hp | 400 lb-ft | 11,600 lbs | High |
| High-Output 3.5L EcoBoost (Raptor) | 2017-present | 450 hp | 510 lb-ft | 8,200 lbs (2024 Raptor) | Good |
| 3.0L Power Stroke Diesel | 2018-2021 | 250 hp | 440 lb-ft | See Ford’s towing guide for your model year | Good |
| 3.5L EcoBoost | 2021-present | 400 hp | 500 lb-ft | 14,000 lbs (2021-2023); 13,500 lbs (2024) | Good |
| 3.5L PowerBoost Hybrid | 2021-present | 430 hp | 570 lb-ft | 11,200-12,700 lbs (by year) | Good |
| 5.0L Coyote V8 (Gen 3) | 2021-present | 400 hp | 410 lb-ft | 12,000 lbs (2024) | High |
| 2.7L EcoBoost (current base) | 2024-present | 325 hp | 400 lb-ft | 8,400 lbs (2024) | Good |
| 5.2L Supercharged V8 (Raptor R) | 2023-present | 700 hp (2023); 720 hp (2024+) | 640 lb-ft | 8,700 lbs | Good |
Max towing figures are Ford’s best-equipped ratings for the model year shown (from Ford tech specs and towing guides). Your truck’s rating depends on cab, bed, axle ratio and tow package, so check the towing guide for your exact configuration. Reliability tags are our summary of owner-reported patterns, not Ford data.
2.7L EcoBoost vs 3.5L EcoBoost Specs and Reliability
The 3.5L EcoBoost has always out-muscled the 2.7L, and the gap is wider than the displacement difference suggests. The current 3.5L PowerBoost and standard-output 3.5L both clear 400 lb-ft of torque, while the 2.7L tops out at 400 lb-ft only in its updated 2018+ form and pulls meaningfully less at low RPM. For anyone towing regularly, the 3.5L is the stronger pick; for daily-driver duty with occasional light towing, the 2.7L’s smaller turbos and lighter front end make it the easier engine to live with.
Reliability tells a more complicated story. Cam phaser failure has affected both engines. Owners on f150forum.com and f150ecoboost.net report the telltale cold-start rattle showing up anywhere from 31,000 to 160,000 miles on Gen 1 and Gen 2 3.5L EcoBoosts, with dealer repair quotes commonly landing between $4,500 and $5,000.
The 2.7L wasn’t spared either; owners on f150gen14.com have reported the same rattle as early as 14,000 miles on 2023 model-year trucks. The redesigned Gen 3 phaser used from roughly 2021 onward is holding up well so far, with multiple owners passing 100,000 miles without the issue resurfacing, though it’s too early to call it fully resolved.
For a deeper breakdown of how these two engines stack up long-term, see our 3.5L EcoBoost vs 5.0L reliability comparison.
5.0L Coyote V8 Specs and Long-Term Reliability
The 5.0L Coyote is the engine most F-150 owners point to when asked which one to buy with the least worry. Output climbed steadily across three generations: 360 hp/380 lb-ft in the 2011-2014 Gen 1, up to 395-400 hp in the Gen 3 versions found in 2018-2024 trucks. Unlike the EcoBoost engines, the Coyote has no widespread cam phaser failure pattern reported at scale, and it’s often reported by owners to pass 250,000 miles with routine maintenance (individual results vary).
That durability comes with a trade-off in outright torque and towing versus the 3.5L EcoBoost, so the Coyote suits owners who prioritize long-term simplicity and naturally aspirated reliability over maximum tow numbers. For the full breakdown of the current Gen 3 architecture, see our Gen 3 Coyote engine specs guide.
3.3L V6 and 5.2L Supercharged V8 (Base and Raptor R Extremes)
The 3.3L Ti-VCT V6 served as the F-150’s base engine from 2018 through 2023 (2015–2017 trucks used a 3.5L Ti-VCT V6), putting out 290 hp and 265 lb-ft with an 8,200-lb max tow rating. It’s a fine choice for light-duty work and daily commuting, but it’s the weakest engine in the modern lineup for anyone who tows or hauls with any regularity, and Ford has since replaced it with the 2.7L EcoBoost as the new base engine starting in 2024. For a closer look at where the 2.7L sits in the lineup now that it holds the entry-level slot, see our 2.7L EcoBoost specs breakdown.
At the opposite extreme sits the 5.2L Supercharged V8, exclusive to the Raptor R since 2023. It produces 700 hp (720 hp from the 2024 model year) and 640 lb-ft of torque, built for high-speed off-road performance rather than towing efficiency, and its 8,700-lb tow rating actually trails several other engines in the lineup because towing was never the design priority.
Which Ford F-150 Engine Tows the Most by Year
Based on the chart above, the standard-output 3.5L EcoBoost holds the F-150’s highest conventional towing figures across most model years, peaking at 14,000 lbs in the 2021-2023 trucks. The 3.0L Power Stroke diesel (see Ford’s towing guide for your model year) and the 3.5L PowerBoost hybrid (11,200 to 12,700 lbs depending on year) trail the gas 3.5L despite their torque, largely because of how Ford packages max-tow options. If you’re cross-shopping towing figures against a specific model year and configuration rather than engine alone, our Ford F-150 towing capacity chart by year breaks down the exact numbers by trim and package.
FAQ — Ford F-150 Engine Questions Owners Ask
Which F-150 engine is most reliable?
The 5.0L Coyote V8 has the strongest long-term track record, with owners commonly reporting 250,000-300,000 miles before major work. It doesn’t share the cam phaser failure pattern seen across the EcoBoost lineup.
Is the 2.7L EcoBoost as strong as the 5.0L V8?
Not in horsepower or towing. The 2.7L makes 325 hp versus 400 hp, and Ford rates the 5.0L to tow more (12,000 vs 8,400 lbs for 2024). Peak torque is close (400 vs 410 lb-ft), and the turbo 2.7L reaches it much lower in the rev range, so it feels strong in daily driving.
What engine did the F-150 have in 2018?
2018 F-150 buyers could choose from the 3.3L V6, updated 2.7L EcoBoost, 3.5L EcoBoost (Gen 2), 5.0L Coyote (Gen 3), and the 3.0L Power Stroke diesel, plus the high-output 3.5L EcoBoost in the Raptor.
Which F-150 engine should I avoid?
The 2011-2016 Gen 1 3.5L EcoBoost has the widest-reported history of cam phaser failures and intercooler condensation issues at higher mileage, making it the engine to inspect most carefully on a used truck.
Conclusion
There’s no single “best” Ford F-150 engine, only the right one for how you use the truck. The 5.0L Coyote remains the safest long-term bet for owners who want naturally aspirated simplicity, the 3.5L EcoBoost still leads the lineup on towing, and the 2.7L EcoBoost and PowerBoost hybrid both make strong cases for daily-driver efficiency. Whatever year or trim you’re comparing, cross-check the engine against its reported reliability pattern before you buy, not just its spec sheet.
