Ford F-150 Oil Capacity Chart: Every Year and Engine
Ford F-150 oil capacity ranges from 6.0 to 8.8 quarts with the filter, depending on the exact year and engine under the hood. That range is too wide to trust blindly, especially since Ford changed the 5.0L V8’s capacity twice in the last decade without much fanfare. Below is the full year-by-year, engine-by-engine breakdown, plus the one number swap that catches even experienced owners off guard.
How to Read the F-150 Oil Capacity Chart
Every figure in this chart includes a new oil filter, since replacing the filter during an oil change is standard practice and adds roughly a quarter-quart to the total. If you’re not sure which engine your truck has, check the door jamb sticker, the oil fill cap, or your VIN through Ford’s build sheet.
- Capacity figures below are quarts, filter included
- “Recommended Oil Type” lists viscosity only; full WSS spec codes are in the table further down
- Always confirm with the dipstick after a brief run and settling period, since dipstick behavior can vary slightly even within a correct fill
Here’s the full breakdown by generation and engine.
Ford F-150 Oil Capacity by Year and Engine 1997 to 2026
| Year Range | Engine | Oil Capacity (Qt, With Filter) | Recommended Oil Type |
|---|---|---|---|
| 1997–2003 | 4.6L V8 (Modular) | 6.0 qt | 5W-30 |
| 2004–2010 | 4.6L V8 (Modular) | 6.0 qt | 5W-20 |
| 1997–2010 | 5.4L V8 (Triton) | 7.0 qt | 5W-20 |
| 2011–2017 | 5.0L V8 (Coyote, Gen 1) | 7.7 qt | 5W-20 |
| 2018–2020 | 5.0L V8 (Coyote, Gen 2) | 8.8 qt | 5W-20 |
| 2021–2026 | 5.0L V8 (Coyote, Gen 3) | 7.7 qt | 5W-20 |
| 2011–2016 | 3.5L EcoBoost V6 (Gen 1) | 6.0 qt | 5W-30 |
| 2017–2026 | 3.5L EcoBoost V6 (Gen 2, High Output) | 6.0 qt | 5W-30 |
| 2015–2017 | 3.5L Ti-VCT V6 (Naturally Aspirated) | 6.3 qt | 5W-20 |
| 2015–2026 | 2.7L EcoBoost V6 | 6.0 qt | 5W-30 |
| 2018–2026 | 3.3L Ti-VCT V6 | 6.0 qt | 5W-20 |
| 2021–2026 | 3.5L PowerBoost Full Hybrid V6 | 6.0 qt | 5W-30 |
| 2018–2020 | 3.0L Power Stroke Diesel | 6.5 qt | 5W-30 (API CK-4) |
Why the 5.0L Coyote Capacity Changed Twice Since 2011
The 5.0L Coyote V8 hasn’t used one fixed number across its run. From 2011 through 2017, Ford spec’d it at 7.7 quarts with the filter. Starting with the 2018 redesign, that jumped to 8.8 quarts, confirmed directly from a 2018 owner’s manual excerpt shared on F150Forum. Then in 2021, when the Coyote was redesigned again, the number dropped back to 7.7 quarts.
That mid-run jump has caused real problems. One 2021 F-150 owner on F150gen14 reported a dealership overfilling their truck because the service writer pulled the 2020 spec by mistake, then had to drain and correct it on the spot. If you’re buying oil in bulk, reusing an old service reminder, or working from a chart that only lists “2011-2026: 7.7 to 8.8 quarts,” you can end up a full quart off in either direction.
Recommended Oil Type and WSS Spec for Each F-150 Engine
Capacity is half the equation. Ford’s WSS-M2C codes tell you whether an oil has passed Ford’s own internal testing beyond generic API and ILSAC standards. An oil meeting WSS-M2C946-B1, for example, includes additives specifically tuned to protect EcoBoost engines against low-speed pre-ignition.
| Engine | Viscosity | Ford WSS-M2C Code |
|---|---|---|
| 4.6L / 5.4L Modular and Triton V8 | 5W-20 | WSS-M2C930-A |
| 5.0L Coyote V8 (all generations) | 5W-20 | WSS-M2C930-A / WSS-M2C960-A1 |
| 3.5L EcoBoost (Gen 1) | 5W-30 | WSS-M2C946-A |
| 3.5L EcoBoost (Gen 2) / 2.7L EcoBoost | 5W-30 | WSS-M2C946-B1 |
| 3.3L Ti-VCT V6 | 5W-20 | WSS-M2C930-A |
| 3.5L PowerBoost Hybrid | 5W-30 | WSS-M2C946-B1 |
| 3.0L Power Stroke Diesel | 5W-30 (API CK-4) | WSS-M2C171-F1 |
For the full explanation of what these codes mean and why substituting a non-WSS-rated oil can affect warranty coverage, see our Ford Engine Oil Recommendation Chart.
If you’re doing the change yourself, here’s what else to check.
Oil Filter Numbers for DIY Changes
Motorcraft filter part numbers vary by engine family, and using the wrong one can restrict oil flow.
- 2.7L EcoBoost: FL-2062 or FL-2062-A
- 3.5L EcoBoost (both generations) and 5.0L Coyote (all generations): FL-500-S
- 3.5L PowerBoost Hybrid: FL-500-S
For drain plug socket size and torque spec, we’ve already broken that down separately in our F-150 oil drain plug socket size guide, since it varies by engine and isn’t something worth guessing at.
Extra Oil Care Tips for EcoBoost F-150 Engines
EcoBoost engines are less forgiving of stretched oil change intervals than the naturally aspirated V8s. Turbocharging adds heat that breaks oil down faster, and direct injection increases the risk of low-speed pre-ignition, a condition where fuel ignites before the spark fires and hammers the pistons and rod bearings. Sticking to full synthetic oil that meets WSS-M2C946-B1 helps protect against this.
Oil quality also affects how long your cam phasers last. If you’re chasing a rattling or ticking noise on cold start on a 3.5L EcoBoost, our 3.5 EcoBoost cam phaser replacement guide covers diagnosis and repair in full.
Get the Right Quart Count Before Your Next Oil Change
F-150 oil capacity isn’t one number. It depends on the exact year and engine, and in the case of the 5.0L Coyote, it changed twice in the same generation of truck. Use the chart above to find your exact figure, match it to the right viscosity and WSS spec, and always confirm against your dipstick after the fill settles. Getting this right the first time saves a second trip to top off, or worse, a drained pan after a dealer overfill.
Frequently Asked Questions
How many quarts of oil does a Ford F-150 take?
It depends on the engine, ranging from 6.0 quarts for most V6 engines to 8.8 quarts for 2018-2020 5.0L V8 models. Check the chart above for your exact year and engine combination.
Does F-150 oil capacity include the filter?
Yes, every figure in this chart already accounts for a new oil filter. If you’re topping off without replacing the filter, you’ll typically use slightly less.
What oil type does a 2021 F-150 5.0L take?
The 2021 and newer 5.0L Coyote V8 takes 7.7 quarts of 5W-20, a change from the 8.8-quart spec used in 2018-2020 models. Always confirm with your owner’s manual since Ford has adjusted this figure more than once.
Can I use 5W-30 instead of 5W-20 in my F-150?
Generally no, unless your owner’s manual or oil cap specifically lists 5W-30 as an approved alternate. Using the wrong viscosity can affect fuel economy and cold-start protection.
How often should I change the oil in my F-150?
Most F-150s use an oil life monitor that adjusts based on driving conditions, typically triggering a change between 7,500 and 10,000 miles. Towing or heavy-duty use shortens that interval, so follow the dash reminder rather than a fixed mileage.
