Ford Edge Towing Capacity Guide: Yearly Ratings And Key Facts

The Ford Edge has built a reputation as a midsize SUV that blends everyday comfort with surprising capability, and one of the most important aspects buyers want to know is its towing performance. Whether you’re hauling a small fishing boat for a weekend trip, bringing along a pop-up camper, or moving a utility trailer, knowing the Ford Edge towing capacity for your exact model year is crucial. Over the years, the Edge has offered a range of towing limits based on engine choice, drivetrain, and tow package, and understanding these details can make the difference between a confident haul and an overloaded hitch.

Key Points:

  • Towing capacity ranges from 1,000 lbs to 3,500 lbs in the U.S. (up to ~2,200 kg in the U.K.)
  • Maximum ratings require the proper Class II Trailer Tow Package
  • Engine type and drivetrain do not always increase capacity but can affect performance
  • Payload and passenger weight can reduce available towing capability

Quick Answer – Ford Edge Towing Capacity At A Glance

If you’re looking for the short version: the Ford Edge towing capacity in U.S. specs tops out at 3,500 pounds when properly equipped with the Class II Trailer Tow Package. In the U.K., the braked towing limit is around 2,200 kg. Lower trims or non-equipped models may have limits as low as 1,000–1,500 lbs. Always check your VIN plate for the exact number on your specific vehicle.


Ford Edge Towing Capacity By Year

Year-By-Year Towing Capacity Table (2007–2025)

Model Year Engine Options Max Towing (lbs) Max Towing (kg) Tow Package Required Notes
2025 2.0L I4 / 2.7L V6 3,500 ~1,588 Yes AWD & tow package for max
2024 2.0L I4 / 2.7L V6 3,500 ~1,588 Yes Same for both engines
2023 2.0L I4 / 2.7L V6 1,500–3,500 ~680–1,588 Yes for 3,500 Some V6 trims rated 3,000 lbs
2022 2.0L I4 / 2.7L V6 3,500 ~1,588 Yes Tow Package Code 53G
2021 2.0L I4 / 2.7L V6 1,000–3,000 ~454–1,361 Yes for 3,000 Trim dependent
2020 2.0L I4 / 2.7L V6 3,500 ~1,588 Yes Payload up to 1,146 lbs
2014–2013 3.5L V6 / 3.7L V6 2,000 ~907 No All trims same rating
2010 3.5L V6 2,000 ~907 No All trims same rating
2007–2012 3.5L V6 1,500–3,500 ~680–1,588 Yes for higher rating Axle ratio & tow package matter

Data compiled from manufacturer specs, dealer information, and towing capacity databases.


U.S. vs. U.K. Ford Edge Towing Specs

While U.S. models list towing capacity under SAE J2807 standards, U.K. ratings often list both braked and unbraked limits. The U.K. figure of ~2,200 kg refers to braked towing (trailers with their own brakes), which is slightly higher than the U.S. figure in pounds because of testing differences. Unbraked limits are much lower—always check your handbook before hitching up.


What You Can Tow With a Ford Edge

Light-Duty Towing (1,000–1,500 lbs)

Think small and lightweight—single jet ski trailers, small utility trailers, dirt bikes. These are well within the Edge’s lower-range capabilities without pushing the drivetrain.

Mid-Range Towing (2,000–3,000 lbs)

Here you’re looking at pop-up campers, small fishing boats, and medium-sized utility trailers. Even without the max tow package, many mid-range loads are manageable with proper weight distribution.

Maximum Towing (3,500 lbs / 2,200 kg)

At full capacity, the Ford Edge can pull teardrop campers, larger fishing boats, or compact travel trailers. One owner I spoke with regularly hauls a 3,200 lb fiberglass camper across Colorado mountain passes with a 2.7L EcoBoost Edge ST, noting the importance of trailer brakes and moderate speeds downhill.


Ford Edge Tow Packages And Features

Class II Trailer Tow Package

Available on SEL and Titanium, standard on ST, this package includes:

  • Trailer sway control for stability
  • Hitch receiver
  • Wiring harness for trailer lights/brakes

Other Towing Features

Even without the tow package, the Edge’s AdvanceTrac with Roll Stability Control, Curve Control, Traction Control, and Hill Start Assist provide a safety net, but they do not replace the mechanical equipment required for maximum towing.


Engine & Drivetrain Impact On Towing

2.0L EcoBoost I4 vs. 2.7L EcoBoost V6

Both can hit 3,500 lbs when properly equipped, but the V6 has an advantage in torque delivery, making it feel less strained on steep grades or when merging with traffic while towing.

AWD vs. FWD

AWD improves stability and traction, particularly in wet or gravel conditions, but does not automatically increase the rated towing limit—it still depends on package and trim.


Ford Edge Towing Capacity Reference Table – Common Loads

Item Approx. Weight (lbs) Suitable For Edge Rating
Jet ski trailer 1,000–1,200 Light-duty
Pop-up camper 1,800–2,500 Mid-range
Small fishing boat 2,500–3,000 Mid-range
Teardrop camper 2,800–3,500 Maximum
Utility trailer w/ ATVs 2,000–3,200 Mid to max

Real-World Ford Edge Towing Stories

Ford Edge owners often share positive towing experiences within limits. For example, one Edge Titanium AWD 2.0L owner towed a 2,800 lb boat to multiple lakes without issue, highlighting the importance of using tow/haul mode and keeping up on brake maintenance. Another Edge ST driver reported hauling a fully loaded small camper over 1,200 miles, praising the sway control for confidence in crosswinds.


Safety & Legal Considerations

VIN Plate and Payload Ratings

Your VIN plate is your most reliable source for exact towing specs. It also lists the GVWR (Gross Vehicle Weight Rating) and payload capacity, both of which directly affect towing safety.

Braked vs. Unbraked Towing (U.K.)

If you’re in the U.K., remember: braked trailers have their own braking system and can be towed up to the higher limit (~2,200 kg for the Edge), while unbraked trailers are restricted to around 750 kg or less.


Ford Edge Towing FAQs

Can a Ford Edge tow 5,000 lbs?
No, the maximum official rating in the U.S. is 3,500 lbs (~2,200 kg in the U.K.) with the proper tow package.

Do I need a tow package to reach the maximum capacity?
Yes, without the Class II Trailer Tow Package, your limit will be lower—often around 1,500–2,000 lbs.

Can a 4-cylinder Edge tow effectively?
Yes, the 2.0L EcoBoost can tow up to 3,500 lbs when properly equipped, though the V6 may offer better performance under heavy load.

Does AWD increase towing capacity?
No, AWD improves traction and handling but does not raise the rated limit; the tow package is the determining factor.

Where can I get the most accurate towing number for my Edge?
Check the VIN plate on your vehicle, located under the bonnet or on the driver’s side door sill.
